PRODUCT

—

Skilled in subtle details

  • enamelled round copper wire
  • enameled round flat wire



STRUCTURE



Enamelled copper round wire is a two-layer structure made by coating a self-adhesive layer of thermoplastic resin or thermosetting resin on a single layer of insulated enameled wire such as polyurethane, polyester, or polyesterimide, and baking it. Our company combines various insulation paint layers and self-adhesive layers to form various self-adhesive enameled copper round wires. Please choose the appropriate wire according to the bonding method and purpose.


modelname

Specification

range

notes
UEW/155[QA/155]155级聚氨酯漆包铜圆线0.030-1.600

IEC 60317-20

NEMA MW 79C JIS 3202

UEW/180[QA/180]180级聚氨酯漆包铜圆线0.030-1.600

IEC 60317-51
NEMA MW 82C JIS 3202

PEW/155[QZ/155]155级聚酯漆包铜圆线0.030-4.500

IEC 60317-3
NEMA MW 5C JIS 3202

EIW/180[QZY/180]180级聚酯亚胺漆包铜圆线0.030-4.500

IEC 60317-8
NEMA MW 30 JIS 3202

SEIW/180[QZYHB/180]180级可焊聚酯亚胺漆包铜圆线0.030-1.600

IEC 60317-23
NEMA MW 77 JIS 3202

EI/AIW200[Q ( ZY/XY ) 200]200聚酰胺酰亚胺复合聚酯亚胺漆包铜圆线0.030-4.500

IEC 60317-13
MW 35C 73C JIS 3202

AIW200[QXY200]200级聚酰胺酰亚胺漆包铜圆线0.030-4.500

IEC 60317-26
MW 81 C JIS 3202

PIW240[QY(F)240]240级芳族聚酰亚胺漆包铜圆线0.050-4.500

IEC 60317-46
MW 16-C

QP200200级耐电晕漆包铜圆线0.200-4.500GB/T 21707
UE/SB155155级自粘性直焊聚氨酯漆包铜圆线0,100-1.600IEC 60317-35
SEIW/SB 180180级自粘性直焊聚酯亚胺漆包铜圆线0,100-1.600IEC 60317-36
EIW/SB 180180级自粘性聚酯亚胺漆包铜圆线0,100-1.600IEC 60317-37
EIAIW/SB 200200级自粘性聚酯亚胺复合聚酰胺酰亚胺漆包铜圆线0,100-1.600IEC 60317-38
